SPECIFICATIONS AND OPERATING REQUIREMENTS
Introduction
Version 5 Model 200i and 250i Motorcycle Dynamometer Installation Guide
1-3
CONVENTIONS USED IN THIS MANUAL
The conventions used in this manual are designed to protect both the user and the
equipment.
TECHNICAL SUPPORT
For assistance, please contact Dynojet Technical Support at 1-800-992-3525, or write
to Dynojet at 2191 Mendenhall Drive, North Las Vegas, NV 89081.
Visit us on the World Wide Web at www.dynojet.com where Dynojet provides state of
the art technical support, on-line shopping, 3D visualizations, and press releases
about our latest product lines.
YOUR DYNO ROOM
This section is not meant to imply that a dyno room is essential to repeatable results
on a Dynojet dynamometer. However, a dyno room with an engine cooling intake fan,
exhaust extraction, and noise reduction capabilities can add a new dimension to your
shop.
A proper dyno room design will help to ensure repeatable, accurate runs. A good
dyno room should do the following:
minimize noise
provide a controlled environment for testing
provide a view window (safety glass) for customers
be designed with safety in mind
Intake Air Fan—After building your dyno room, you will need to supply an intake air
fan. The intake air fan supplies air to cool the bike’s engine while supplying fresh
oxygen for you and your bike to breathe. It is a common misconception that you
cannot tune a bike without a large fan simulating exact road conditions; however, a
good cooling fan is the only requirement for consistent diagnostics and tuning. The
installed fan should be 5200 CFM.
example of convention description
The Caution icon indicates a potential hazard to the
dynamometer equipment. Follow all procedures
exactly as they are described and use care when
performing all procedures.
The Warning icon indicates potential harm to the
person performing a procedure and/or the
dynamometer equipment.
#
RECORD
The Record # icon reminds you to record your
dynamometer and/or eddy current brake (retarder)
number on the inside cover of this manual.
Bold
Highlights items you can select on in the software
interface, including buttons and menus.
!
The arrow indicates a menu choice. For example,
“select
File
!
Open means “select the File menu,
then select the
Open choice on the File menu.”
