5-1
Above Ground Model 250i Motorcycle Dynamometer Installation Guide
CHAPTER 5
B
ASIC
D
YNO
O
PERATION
The Dynojet Dynamometer gives you the state of the art technology, durability, and
accuracy that you need. Dynojet’s advanced engineering delivers the precise
horsepower measurements a technician needs to make quick and accurate evaluations
of engine performance and drivetrain problems.
This chapter includes instructions for basic dyno operation. For more detailed
instructions, refer to the Power Core Help.
This chapter is divided into the following categories:
• Loading the Vehicle, page 5-2
• Connecting the RPM Pickup, page 5-4
• Grounding the Vehicle, page 5-9
• Pre-Run Inspection, page 5-10
•Using the Starter, page 5-12
• Using the Dyno, page 5-12
• Making a Test Run, page 5-13
• Preventative Maintenance, page 5-14
