Model 200i and 250i Motorcycle Dynamometer Installation Guide
APPENDIXB
Locations Using 60Hz Power (North America & Japan)
B-6
CONNECTING THE DYNO
1 Turn off the main circuit breaker on the dyno. The main breaker is located in the
CPI door. Refer to page 3-2 for breaker location. Off is the down position.
2 Once you verify the voltages on the receptacle, connect the dyno to the
receptacle.
3 Connect the high pressure blowers to the dyno. For more information on
connecting the blowers, refer to “Connecting Power to the Blowers” on page 3-
41.
4 Turn on the main dyno breaker. Refer to page 3-2 for breaker location.
5 Test the blowers for operation.
6 Turn on the dyno electronics and verify operation.
7 Test the control panel operations. Refer to “Final Adjustments and Tests” on page
3-49.
