3-41
ACCESSORIES
Final Adjustments and Tests
Version 4 Above Ground Model 250i Motorcycle Dynamometer Installation Guide
FINAL ADJUSTMENTS AND TESTS
After you have installed all of your additional accessories and routed all necessary
cables, perform the following procedures to ensure the safe and effective operation of
your dyno.
Note: Before replacing the top cover, if your country requires you install the
safety switch, please refer to the instructions in Appendix B.
TURNING ON THE DYNO POWER
Use the following steps to connect (and disconnect) power to the dyno. Always turn
the power off when connecting and disconnecting cables.
1 Plug the power plug into the power outlet.
2 Turn on the main breaker inside the CPI door. Refer to “Main Dyno Power” on
page 3-2.
3 Close the CPI door.
Note: Use the main breaker to turn power on and off to the dyno.
POWER CARRIAGE FINAL ADJUSTMENTS AND TESTS
Using the control panel, press the carriage forward and backward buttons and verify
that the motor does turn. Refer to “Using the Power Carriage” on page 4-6 for more
information on using the power carriage.
WHEEL CLAMP FINAL ADJUSTMENTS AND TESTS
1 Place a stack of catalogs into the wheel clamp.
2 Using the control panel, press the close button and observe that the wheel clamp
does close. Hold the button until the motor turns off and the status light is on
steady.
3 Press and hold the right hand wheel clamp button then press the left hand button
to open the clamp.
Refer to “Using the Wheel Clamp” on page 4-7 for more information on using the
control panel.
