ACCESSORIES
Air Brake
Version 5 Model 200i and 250i Motorcycle Dynamometer Installation Guide
3-15
CHANGING THE BRAKE PADS
To prevent possible injury, open the CPI door and set the main breaker to the
off position and unplug the dyno. Refer to Figure 3-1 for breaker location.
1 Remove the top and right side covers from the dyno. Refer to page 3-3.
2 For safety, apply the brake and disconnect the air supply at the front of the dyno.
Refer to Figure 3-6 on page 3-7.
3 Remove the hairpin cotter and loosen the castle nut until the pads clear the rotor.
Figure 3-16: Loosen the Castle Nut
remove hairpin cotter
adjust castle nut
outboard brake pad
