CHAPTER 2
Unpacking and Inspecting the Dyno
Above Ground Model 250i Motorcycle Dynamometer Installation Guide
2-6
10 Remove the boxes and loose parts from the crate, verify their condition and
contents, and set them aside.
part description part description
screw, 8-32 x 3/8", ph, phil
(2)
P/N 36540643
grounding kit
P/N 76100015
see list of parts below
washer, 3/8", flat (4)
P/N 36923100
PCV CAN termination plug
P/N 76423025
anchor, Red Head, 3/8" (4)
P/N 37513200
CAN termination plug
P/N 76423045
installation tool, Red Head
anchor
P/N 37518200
blower assembly
P/N 76722003
optional accessory
see page 3-22
network cable
P/N 42900000
primary inductive
pickup (2)
P/N 76950201
cable harness wrap kit
P/N 43400000
secondary inductive
pickup (2)
P/N 76950203
cable clamp (7)
P/N 43428232
cable, wheel clamp
P/N 76950307
optional accessory
To Next Page
