SPECIFICATIONS AND OPERATING REQUIREMENTS
Dynamometer Specifications and Requirements
Version 5 Model 200i and 250i Motorcycle Dynamometer Installation Guide
1-7
COMPRESSED AIR REQUIREMENTS
The following requirements are needed when the optional air brake is included.
• regulator set to 65 psi max (450 kilopascal)
•air dryer
• shut off valve
• gauge on the regulator
• 1/4-inch NPT pipe thread connector (to attach air to the dyno)
COMPUTER SPECIFICATIONS
You will need to provide a computer system to run the WinPEP software. WinPEP 7
includes complete documentation in online Help. From the WinPEP 7 menu bar,
choose Help
!
WinPEP 7 Help or visit www.winpep.com (accessible with a valid user
name and password). Refer to the section on Computer Specifications in the WinPEP
documentation, P/N 98118103, for the specific computer system requirements.
ELECTRICAL REQUIREMENTS
The Model 200i/250i dynamometers require a 240V - 30a single-phase electrical
circuit for reliable and precise operation. No other loads should be plugged into this
circuit and this circuit should be independent of the lighting in the dyno room.
Before you plug in your dyno, you or your electrician must refer to Appendix B for
detailed information.
description specifications
Power Requirements 240v 30 amp single phase circuit
Frequency 50 or 60 Hz
Voltage
normal 240 VAC
min./max 215 VAC/245 VAC except Japan 195 VAC/245 VAC
Current 30 amps
Power Consumption 7200 watts
Power Cord P/N 76950401
length 3.048 m (10 ft.)
end twist-lock plug or three-pin IEC plug
wall receptacle (included with dyno) twist-lock four wire grounded 30A NEMA L14-30 or
three-pin IEC grounded 30A
Full Load Amperage (FLA) 30A
