INSTALLATION
Dyno Installation
Version 5 Model 200i and 250i Motorcycle Dynamometer Installation Guide
2-3
4 Remove the six 1/4-inch screws securing the center panel on the dyno and remove
the center panel.
Note: Dynojet recommends using a T30 Torx driver (Snap-On PFTx30E) to
remove the 1/4-inch screws. For dynos with serial numbers lower than 2030152,
Dynojet recommends using a hardened 5/32-inch hex driver (such as Snap-On
FA5E). A standard allen key may round off in the shallow screw head.
5 Remove the tire stop, tire lock, and hardware from the middle of the dyno.
Figure 2-2: Remove the Center Panel
center panel
tire stop and tire lock
in middle
