Model 200i and 250i Motorcycle Dynamometer Installation Guide
CHAPTER 2
Dyno Installation
2-4
6 Remove the eight screws securing the top drum cover to the dyno and set aside.
Remove the drum cover and set aside.
7 Remove the two top screws securing each side drum cover to the dyno and set
aside.
Figure 2-3: Remove the Top Drum Cover
top drum cover
side drum cover
side drum cover
