Dynojet 200i - MODEL 250 I MOTORCYCLE DYNAMOMETER

Model 200i and 250i Motorcycle Dynamometer Installation Guide
CHAPTER 1
Model 250i Motorcycle Dynamometer
1-10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MODEL 250i MOTORCYCLE DYNAMOMETER
Figure 1-4: Model 250i With Optional Accessories
High Pressure Blower
cools the bike’s engine
Eddy Current
Brake Module
Air Brake
Air Pump
Assembly
Power Carriage
not shown
Theta Controller
controls the eddy
current brake
Monitor Tray
supports the monitor,
keyboard, and mouse
Tire Carriage
Tie-down Loop
used to secure the
motorcycle to dyno
Drum
precision balanced
and knurled
Wheel Clamp
not shown
Control Panel
not shown
