CHAPTER 5
Connecting the RPM Pickup
Above Ground Model 250i Motorcycle Dynamometer Installation Guide
5-6
Depending on accessibility, the user can make a primary wire hookup from the coil or
the ignition module. Ignition modules can be found usually under the seats or side
covers. Refer to the following table to determine the wire color when hooking up the
inductive tack lead to the primary side of the ignition.
make wire color
BMW R Models Black
BMW K Models Black/Blue
Black/Red
BMW Triplets Black/Green
Buell Pink
Ducati Gray or Green/Brown
EFI Green or Violet/Yellow
Harley Blue or Pink
Honda Yellow or Yellow/Blue
Kawasaki Green
Suzuki White or Black/Blue
Triumph Brown/Yellow
Yellow/Blue
Green/Black
Black/Green
Yamaha Orange or Gray
