Model 200i and 250i Motorcycle Dynamometer Installation Guide
CHAPTER 1
Dynamometer Specifications and Requirements
1-6
Figure 1-2: Model 200i and 250i Dimensions
model 200i
model 250i
202.77 cm
(79.83 in.)
106.68 cm
(42.00 in.)
152.40 cm
(60.00 in.)
127.74 cm
(50.29 in.)
202.77 cm
(79.83 in.)
179.60 cm
(70.71 in.)
72.92 cm
(28.71 in.)
carriage: allow 68.33 cm (26.9 in.)
extended carriage: allow
119.38 cm (47.0 in.)
45.97 cm (18.10 in.)
45.97 cm (18.10 in.)
carriage: allow 68.33 cm (26.9 in.)
extended carriage: allow
119.38 cm (47.0 in.)
