CHAPTER 4
Introduction
Above Ground Model 250i Motorcycle Dynamometer Installation Guide
4-2
INTRODUCTION
The control panel interface (CPI) consists of a main control board which is mounted
internal to the 200i/250i motorcycle dyno or in an external box for a pit dyno or
retrofit. This board provides switching and control of many functions within the dyno.
The front panel of this board is accessible through the side door on the dyno or door
on the external box. The user interface is through the control panel which is normally
mounted on the side of the monitor tray. The control panel allows the user to control
the following items:
Optional AFR Air Pump
Optional High Pressure Blowers
Optional Power Carriage
•Starter
•Optional Wheel Clamp
The CPI main control board has an on-board microprocessor which reads the user
input from the control panel, monitors interlock and E-Stop inputs, and controls the
various dyno outputs. The CPI is powered internally from the main power that is
provided to the dyno. The power supplied is 240VAC 50 or 60 Hz.
