CHAPTER 3
Power Carriage
Above Ground Model 250i Motorcycle Dynamometer Installation Guide
3-36
REMOVING THE HAND WHEEL
To prevent possible injury, open the CPI door and set the main breaker to
the off position and unplug the dyno. Refer to “Main Dyno Power” on page
3-2 for breaker location.
1 Loosen the set screw on the hand wheel and remove the hand wheel.
2 Using a 7/16-inch wrench, remove the two bolts securing the flange bearing.
Figure 3-36: Remove the Hand Wheel
bolt
flange bearing
hand wheel
