BASIC DYNO OPERATION
Loading the Bike
Version 5 Model 200i and 250i Motorcycle Dynamometer Installation Guide
5-3
6 Attach the tie-down straps from a solid place on the bike to the tie-downs on the
dyno or the ground hook locations (refer to page 2-43). Position the straps to
allow proper clearance for the brake pedal, the shift lever and the exhaust pipes.
For best results, hook the straps at the rear of the bike so they pull down and
forward.
7 Sit on the bike with your feet on the pegs. Remove the slack from the straps.
Gently shift your weight from side to side while tightening the straps, being
careful to not overtighten the straps. The straps are used to stabilize the bike.
They should not add any additional weight to the bike.
Never perform a dyno run if the tie-down straps are not in place or they are
damaged.
Figure 5-2: Attach the Tie-down Straps
tie-down
tie-down strap
