CHAPTER 2
Tire Carriage Installation
Above Ground Model 250i Motorcycle Dynamometer Installation Guide
2-38
TIRE CARRIAGE INSTALLATION
Be sure the location you have chosen for your dyno has enough room in front of the
dyno for the maximum extension of the carriage. Refer to “Dynamometer
Specifications and Requirements” on page 1-5 for more information. If you ordered
the extended wheel carriage accessory, refer to “Extended Carriage” on page 3-17 and
install it at this time.
The tire carriage is fastened to the bottom of the crate next to the dyno. Refer to
page 2-2 for instructions on removing the tire carriage from the crate.
Note: Before replacing the center panel and installing the tire carriage install the
air hose, the EEC Kit, the door safety switch, and any additional accessories you
may have ordered. Refer to the appropriate sections of this manual for installation
instructions.
You will need the following parts:
• 21224104 Carriage Clamp (3)
• 21224105 Carriage Clamp Spacer (3)
• 21224106 Nut Block Spacer
• 36580434 Bolt, 3/8-16 x 1/2", Bh-Flange (8)
• 61324102 Nut Block
• 63310902 Tire Stop
•71323002 Standard Carriage
• DM150-002-003 Lock Washer, 5/16" (8)
• DM150-002-004 Bolt, 5/16-18 x 1.5", Hex (8)
•DM150-016-006Hand Wheel
