Model 200i and 250i Motorcycle Dynamometer Installation Guide
CHAPTER 3
Power Carriage
3-46
7 Place the power carriage motor assembly near the motor mount and plug the
motor connector into the power carriage cable.
8 Turn the carriage screw to align the coupler jaws with each other and slide the
coupler jaws together until the motor assembly cover is flush with the motor
mount.
9 Secure the motor assembly cover to the motor mount with four 1/4-20 x 1/2-inch
button-head screws.
Figure 3-50: Assemble the Power Carriage
PC024C
motor assembly
motor assembly
cover
