D-3
TORQUE VALUES
Standard Bolt Torque Values
Version 4 Above Ground Model 250i Motorcycle Dynamometer Installation Guide
GRADE 8
size torque, plain torque, plated
in-
threads/in in•lb ft•lb N•m in•lb ft•lb N•m
1/4-20 143 12 16 107 9 12
1/4-28 164 14 19 123 10 14
5/16-18 295 25 33 221 18 25
5/16-24 326 27 37 245 20 28
3/8-16 523 44 59 392 33 44
3/8-24 593 49 67 444 37 50
7/16-14 837 70 95 628 52 71
7/16-20 935 78 106 701 58 79
1/2-13 1277 106 144 958 80 108
1/2-20 1439 120 163 1079 90 122
9/16-12 1843 154 208 1382 115 156
9/16-18 2055 171 232 1542 128 174
5/8-11 2543 212 287 1907 159 215
5/8-18 2880 240 325 2160 180 244
3/4-10 4509 376 509 3382 282 382
3/4-16 5036 420 569 3777 315 427
7/8-9 7277 606 822 5457 455 617
7/8-14 8017 668 906 6013 501 679
1-8 10908 909 1232 8181 682 924
1-12 11934 995 1348 8951 746 1011
