E15h SPRAYER- Alarm Setup
NOTE: For the PUMP LOW SPEED and PUMP HIGH SPEED ALARMS to be enabled
on the SHAFT ALARMS screen, the PUMP SPEED SENSOR has to be set to ON.
See Section 3.22 to enable the PUMP SPEED SENSOR ON or OFF
4.2.1 ENABLE THE PUMP SPEED LOW ALARM
• Press MENU
• Press ENTER to select SETUP
• Press LINE 2 the focus is on ALARM SETUP
• Press ENTER to select ALARM SETUP
• Press LINE 2, the focus is on SHAFT ALARMS
• Press ENTER to select SHAFT ALARMS
• Press ENTER to edit PUMP SPEED LOW.
An asterisk(*) will be displayed
• Press INC/DEC buttons, to set the alarm ON or OFF
• Press ENTER to accept the changes
4.2.2
SET THE PUMP SPEED LOW ALARM POINT
• Press MENU
• Press ENTER to select SETUP
• Press LINE 2 the focus is on ALARM SETUP
• Press ENTER to select ALARM SETUP
• Press LINE 2, the focus is on SHAFT ALARMS
• Press ENTER to select SHAFT ALARMS
Note:
If alarm is OFF, to switch the alarm ON, see Section 4.2.1
•Press LINE 1 until the focus is on the ALARM POINT
• Press ENTER to edit the value.
An asterisk(*) will be displayed
• Use INC/DEC buttons, to set the alarm point in 50 rpm increments
• Press ENTER to accept the changes
4.2.3
ENABLE THE PUMP SPEED HIGH ALARM
• Press MENU
• Press ENTER to select SETUP
• Press LINE 2 the focus is on ALARM SETUP
• Press ENTER to select ALARM SETUP
• Press LINE 2, the focus is on SHAFT ALARMS
• Press ENTER to select SHAFT ALARMS
• Press LINE 2, the focus is on PUMP SPEED HIGH
• Press ENTER to edit PUMP SPEED HIGH.
An asterisk (*) will be displayed
• Press INC/DEC buttons, to switch the alarm ON or OFF
• Press ENTER to accept the changes
45
V 1.0 11/05
