E15h SPRAYER- Alarm Setup
4.2.4 SET THE PUMP SPEED HIGH ALARM POINT
• Press MENU
• Press ENTER to select SETUP
• Press LINE 2 the focus is on ALARM SETUP
• Press ENTER to select ALARM SETUP
• Press LINE 2, the focus is on SHAFT ALARMS
• Press ENTER to select SHAFT ALARMS
• If alarm is off, turn the alarm ON, see Section 4.2.3
• Press LINE 2 until the focus is on the ALARM POINT
• Press ENTER to edit the value.
An asterisk (*) will be displayed
• Press INC/DEC buttons, to set the alarm point in 50rpm increments
• Press ENTER to accept the changes
4.2.5
ENABLE THE AUX SHAFT LOW ALARM
NOTE: For the AUX SHAFT LOW and AUX SHAFT HIGH ALARMS to be enabled on
the SHAFT ALARMS screen, the AUX SHAFT SENSOR has to be toggled ON.
See Section 3.22 to switch the AUX SHAFT SENSOR ON or OFF
• Press MENU
• Press ENTER to select SETUP
• Press LINE 2 the focus is on ALARM SETUP
• Press ENTER to select ALARM SETUP
• Press LINE 2, the focus is on SHAFT ALARMS
• Press ENTER to select SHAFT ALARMS
• Press LINE 3, the focus is on AUX SHAFT LOW
• Press ENTER to edit AUX SHAFT LOW.
An asterisk (*) will be displayed
• Press INC/DEC buttons to switch the alarm ON or OFF
• Press ENTER to accept the changes
4.2.6
SET THE AUX SHAFT LOW ALARM POINT
• Press MENU
• Press ENTER to select SETUP
• Press LINE 2 the focus is on ALARM SETUP
• Press ENTER to select ALARM SETUP
• Press LINE 2, the focus is on SHAFT ALARMS
• Press ENTER to select SHAFT ALARMS
Note: If alarm is OFF, switch the alarm ON, see Section 4.2.5
• Press LINE 3 until the focus is on the ALARM POINT
• Press ENTER to edit the value.
An asterisk (*) will be displayed
• Press INC/DEC buttons, to set the alarm point in 50rpm increments
• Press ENTER to accept the changes
46
V 1.0 11/05
