Eaton 9155 N - Table 4-1: the Floor Surface Must Withstand These Weights (Standard Models); Table 4-2: the Floor Surface Must Withstand These Weights (TA Models)

10 8-10 kVA, 50/60 Hz (1-phase input) &
8-15 kVA, 50/60 Hz (3-phase input)
P-164000341
User's Guide Revision 1
Equipment Standard Weight (kg) Point (kg/cm²) Distributed (kg/m²) Note
UPS 58 0,09 272 No batteries
UPS + BAT 161 0,25 754 Batteries installed
UPS + 2 BAT 265 0,41 1241 Batteries installed
UPS + BAT (EMPTY) 81 0,13 379 No batteries installed
UPS + 2 BAT (EMPTY) 105 0,16 492 No batteries installed
UPS + TRAFO 161 0,25 754 No batteries
UPS + TRAFO + BAT 243 0,38 1138 Batteries installed
2 BAT 217 0.34 1016 Batteries installed
3 BAT 323 0.50 1513 Batteries installed
Table 4-1: The floor surface must withstand these weights (Standard models)
Equipment TA model Weight (kg) Point (kg/cm²) Distributed (kg/m²) Note
UPS 68 0,11 319 No batteries
UPS + BAT 171 0,27 801 Batteries installed
UPS + 2 BAT 275 0,43 1288 Batteries installed
UPS + BAT (EMPTY) 91 0,14 426 No batteries installed
UPS + 2 BAT (EMPTY) 115 0,18 539 No batteries installed
UPS + TRAFO 171 0,27 801 No batteries
UPS + TRAFO + BAT 253 0,40 1185 Batteries installed
2 BAT 217 0.34 1016 Batteries installed
3 BAT 323 0.50 1513 Batteries installed
Table 4-2: The floor surface must withstand these weights (TA models)
