Eaton 9155 N - Table 6-4: Recommended Cable and Fuse Sizes for 9355 N-Model and 9355 NT-Model

36 8-10 kVA, 50/60 Hz (1-phase input) &
8-15 kVA, 50/60 Hz (3-phase input)
P-164000341
User's Guide Revision 1
9355 (3P in/3P out) INPUT PE BATTERY
UPS RATING (kVA) Fusing
(FUSE A)
Cabling
(CABLE 1)
Cabling
(CABLE 1)
Fusing
(FUSE A)
Cabling
(CABLE 3)
8 kVA 16 A 6 mm² 6 mm² 50 A 10 mm²
10 kVA 20 A 6 mm² 10 mm² 50 A 10 mm²
12 kVA 25 A 6 mm² 10 mm² 50 A 10 mm²
15 kVA 32 A 10 mm² 10 mm² 50 A 10 mm²
9355 (3P
in/3P
out)
OUTPUT
Nominal Current
with different output voltages
Cabling (CABLE 2)
with different output voltages
UPS
RATING
(kVA)
230 V 400 V 440 V 480 V 690 V 230 V 400 V 440 V 480 V 690 V
8 kVA 20,1 A 11,6 A 10,5 A 9,7 A 6,7 A 6 mm² 2,5
mm²
2,5
mm²
2,5
mm²
2,5
mm²
10 kVA 25,2 A 14,5 A 13,2 A 12,1 A 8,4 A 10
mm²
6 mm² 2,5
mm²
2,5
mm²
2,5
mm²
12 kVA 30,2 A 17,4 A 15,8 A 14,5 A 10,1 A 10
mm²
6 mm² 6 mm² 2,5
mm²
2,5
mm²
15 kVA 37,7 A 21,7 A 19,7 A 18,1 A 12,6 A 16
mm²
10
mm²
6 mm² 6 mm² 6 mm²
Table 6-4: Recommended cable and fuse sizes for 9355 N-model and 9355 NT-model
