Eaton 9155 N - Table 14-5: AC Input

90 8-10 kVA, 50/60 Hz (1-phase input) &
8-15 kVA, 50/60 Hz (3-phase input)
P-164000341
User's Guide Revision 1
UPS 8 kVA 10 kVA 12 kVA 15 kVA
Voltage (L-N) without
transformer
192 to 253 Volts without using battery
Voltage (L-N) with input
transformer
±5% of system nominal voltage without using battery
Frequency 45 to 65 Hz
Power factor 0.99
Input
distortion
< 5% THD(I)
Rated input current Input voltage 8 kVA 10 kVA 12 kVA 15 kVA
120 V 39 A 49 A 58 A 73 A
230 V 21 A 26 A 31 A 38 A
400 V 12 A 15 A 18 A 22 A
440 V 11 A 14 A 16 A 20 A
480 V 10 A 13 A 15 A 19 A
3-phase
690 V 7 A 9 A 11 A 13 A
120 V 67 A 84 A - -
230 V 35 A 44 A - -
400 V 20 A 25 A - -
440 V 19 A 23 A - -
480 V 17 A 21 A - -
1-phase
690 V 12 A 15 A - -
Table 14-5: AC input
DC circuit
UPS 8 kVA 10 kVA 12 kVA 15 kVA
Management Advanced Battery Management
Nominal voltage 384 Volts
Battery qty 32 pcs.
Float voltage 2.30 VPC
