Eaton 9155 N - Table 6-1: Recommended Cable and Fuse Sizes for 9155 N-Model (no Transformer)

P-164000341 8-10 kVA, 50/60 Hz (1-phase input) &
8-15 kVA, 50/60 Hz (3-phase input)
23
Revision 1 User's Guide
9155 (3P in/1P out) RECTIFIER INPUT BYPASS INPUT
UPS rating (kVA)
Fusing
(FUSE A)
Cabling
(CABLE 1)
Fusing
(FUSE B)
Cabling
(CABLE 2)
8 kVA 25 A 6 mm² 50 A 10 mm²
10 kVA 25 A 6 mm² 50 A 10 mm²
12 kVA 40 A 10 mm² 63 A 16 mm²
15 kVA 50 A 10 mm² 80 A 16 mm²
9155 (3P in/1P out) PE Output Battery
UPS rating (kVA) Cabling
(CABLE 2)
Nominal
current
Cabling
(CABLE 2)
Fusing
(FUSE A)
Cabling
(CABLE 3)
8 kVA 10 mm² 38.8 A 10 mm² 50 A 10 mm²
10 kVA 10 mm² 43.5 A 10 mm² 50 A 10 mm²
12 kVA 16 mm² 52.2 A 16 mm² 50 A 10 mm²
15 kVA 16 mm² 65.2 A 16 mm² 50 A 10 mm²
Table 6-1: Recommended cable and fuse sizes for 9155 N-model (No transformer)
