56 8-10 kVA, 50/60 Hz (1-phase input) &
8-15 kVA, 50/60 Hz (3-phase input)
P-164000341
User's Guide Revision 1
The UPS shall check its internal functions, synchronise to bypass and start to supply the load. The
green LED is blinking if there occurs an active notice. In normal operation the green LED is constantly
lit if no new active notice such as ‘unsynchronised’ or similar notices present.
The output voltage shall be verified from the output measurements screen of the LCD. If there is
voltage in the output then UPS is supplying the load.
8.4 Battery start-up
UPS will start on battery if mains is not available. Note that the UPS behavior may be slightly different
from the normal start-ups.
8.5 Start-up after EPO
1. Find out the reason that caused EPO.
2. Check that there are no risk to start the UPS again.
3. Follow Normal start-up check list and procedure.
8.6 Shutdown
The procedure to shutdown from LCD is following:
1. Push any key of the control panel to enable the functions of the LCD screen.
2.
Select “TURN UPS OFF” from the LCD menu (see Chapter 8.1 Display functions on page
49).
3.
Press and hold the return button for 5 sec. There shall be an indication sound during the
hold.
4. UPS shall do a shutdown routine.
5. Turn the battery and input circuit breakers to OFF position to finalise the shutdown procedure.
NOTE
The behaviour is different if UPS is turned off from the programmable input or through
communication cards. If battery and input circuit breakers are left ON, UPS will enter a stand-
by mode and starts to charge batteries with a cooling fan operational. Output is without the
voltage in the stand-by mode.
