Eaton 9155 N - Table 14-6: DC Circuit; Table 14-7: AC Output

P-164000341 8-10 kVA, 50/60 Hz (1-phase input) &
8-15 kVA, 50/60 Hz (3-phase input)
91
Revision 1 User's Guide
UPS 8 kVA 10 kVA 12 kVA 15 kVA
Battery type VRLA 12 Volts
Cut off voltage 1.75 VPC
Battery charging
Default: 3 Amps, user selectable
Maximum charging current: 25 Amps (Step 0.1 A)
Table 14-6: DC circuit
AC output
UPS 8 kVA 10 kVA 12 kVA 15 kVA
Active power 7,2 kW 9 kW 10,8 kW 13,5 kW
Nro. of phases 1-phase (2-phase) or 3-phase
Frequency 50 Hz or 60 Hz, user selectable
(9155): 220, 230 or 240 Volts, user selectable
(9355): 380, 400 or 415 Volts, user selectable
Nominal voltage rating
With internal transformer: 120, 230, 400, 440, 480 or 690 Volts
8 kVA 10 kVA 12 kVA 15 kVA
(9155): 100 A, < 300 ms (9155): 144 A, < 300 msShort circuit capability
(9355): 55 A, < 300 ms
Overload capability min >100-110% load
1 min > 110-125% load
5 sec >125-150% load
300 ms >150% load
Table 14-7: AC output
The represented short circuit values are for models without transformers.
