P-164000341 8-10 kVA, 50/60 Hz (1-phase input) &
8-15 kVA, 50/60 Hz (3-phase input)
51
Revision 1 User's Guide
Description Available settings Default setting
General:
Display contrast adjustment + / - Moderate
Display language [English], [Spanish], [French], [Ger-
man]
English (British)
Date & Time [xxxx-xx-xx] 0001-01-01
Audible alarms [Normal], [Disabled] Normal
Normal screen in display [logo], [mimic] Product name
User settings password [Not required], [Set] Not required
Nominal values:
Nominal output voltage (L-N) [220], [230], [240] 230 Volts
Nominal output frequency [50 Hz], [60 Hz] 50 Hz
Rectifier phase current limit Step: 1 A 32 A
Communication and connectivity:
Disable control commands [Enabled], [Disabled] Disabled
Communication speed [1200], [2400], [9600], [19200] 19200 bps.
Std. relay output function [UPS ON/OK], [Custom], [Battery
low], [System on bypass], [System
on battery]
UPS ON/OK
Signal input #1-2 function
[Empty], [see Chapter 7.3.3 Pro-
grammable signal inputs on page
43.]
Empty
Hardware remote off delay for
hardware Remote off with restart
function.
Step: 1 sec. 120 sec.
XSlot relay output 1-4 function
[Nothing], [see Chapter 8.2.4 Using
relay outputs on page 54.]
XSlot defaults:
#1: on battery
#2: battery low
#3: UPS on/ok
#4: on bypass
