8 SmartWire-DT
8.9 Programming
DS7 Soft starter 09/16 MN03901001Z-EN www.eaton.com 183
8.9.3.15 Profile 11: Outputs (control)
Output bytes 0 + 4 are mapped as follows on SmartWire-DT.
Table 39: Profile 11: Output bytes 0 + 4
Word
Bit Designation Meaning
0 0 OnOff Switch on/off
0: Normal stop (with configured ramp time)
1: Operation
1 Off2 Run-down (Coast Stop: Off 2)
0: Coast stop (switch off output voltage)
1: no free run-down
2 Off3 Quick Stop: Off3
0: Quick stop (shortest ramp)
1: no quick stop
3 EN_Op Operation released
0: Stop
1: Operation
4 EN_Ramp Enable Ramp
0: Reset ramp (setpoint value = 0)
1: Release ramp
5 Un-Freeze Freeze ramp
0: Freeze ramp (the ramp generator’s current output value
will be frozen)
1: Do not freeze ramp
6 EN_Set Enable Setpoint, DS7 Start/Stop:
EN_Set enables the setpoint value and starts or stops
the motor with the ramp function.
0: Do not activate setpoint value
1: activate setpoint value
7 FaultAck Fault Acknowledge
0: Do not acknowledge current fault
1: Acknowledge current fault (rising edge: 0 → 1)
8 – Not used
9 – Not used
10 Ctl_PLC PLC assumes control (Control by PLC)
0: no control via PLC
1: Control via PLC
11 - 14 – Not used
15 ExtFault External Fault
If the bit is set, the DS7-SWD stops with a selected
PNU 840 function. The behavior is the same as for a
transition of the Enable signal from 1 to 0, except that soft
starter DS7-SWD switches to Error state (input bytes n + 4:
bit 3).
The external fault can be reset just like any other fault
(with Fault acknowledge (bit 7) or by switching the supply
voltage off and on).
0: no external fault
1: external fault
1
0 - 15 Transmit values of currents from PKE motor-protective
circuit-breaker to DS7 soft starter ￫ section 8.9.3.14,
“Profile 11: outputs (transmitting external current values to
the DS7 soft starter, firmware V48 and higher)”, page 181
