8 SmartWire-DT
8.9 Programming
190 DS7 Soft starter 09/16 MN03901001Z-EN www.eaton.com
860 0 ro Warnings Unsigned32 Warnings
If bit WARN = 1 in profiles 7, 8, 9,
11, a warning is active. The
warning can be read in PNU 860.0.
Reading the warning will only be
possible as long as the warning is
active. Warning bits 16 to 24 will
only be generated if the error
response for the corresponding
fault is (PNU 840.X) = 1.
Example: PNU 860.0: Bit 20 = 1 →
Thyristor fault
2
0
: NoCurrentFeedback
(generated if current limiting
(PNU 681.0) is activated and the
DS7-SWD soft starter has the
RUN status.)
2
1
: OvertempForNextStart (the
heat sink is still too hot for a new
start; however, continuous
operation can be continued.)
2
2
: StartWithoutEnable (start
command active, but no EN signal
present yet)
2
16
: HeatsinkOverUnderTemp
(Heat sink overtemperature/
undertemperature)
2
17
: ElectronicsOverTemp
(Overtemperature Electronic)
2
18
: ThyristorOverTemp
(Overtemperature, thyristor (I
2
t))
2
19
: SupplyVoltageFault (Supply
voltage error)
2
20
: ThyristorFault (Thyristor error)
2
21
: BypassDefective (Bypass is
defective)
2
22
: PhaseLoss (phase failure)
2
23
: CommunicationFault
(erroneous communication)
2
24
: ExternalFault (external fault)
0 - 4294967295
PNU
Index
PNU
Sub-
index
Access
rights
Designation Data type Meaning Value range DS User
setting
