www.eaton.com IM02601001E 7-5
Using the I/O Option Cards
The Pulse Output/Digital Input card is a combination of pulse outputs via solid state contacts and dry/wet contact
sensing digital inputs. The outputs are electrically isolated from the inputs and from the main unit.
Power consumption: 0.420W internal
Relay outputs
Number of outputs: 4
Contact type: Closing (SPST - NO)
Relay type: Solid state
Peak switching voltage: DC ±350V
Continuous load current: 120mA
Peak load current: 350mA for 10ms
On resistance, max.: 35Ω
Leakage current: 1µA@350V
Switching Rate max.: 10/s
Isolation: AC 3750V system to contacts
Reset/Power down state: Open contacts
Inputs
Number of inputs: 4
Sensing type: Wet or dry contact status detection
Wetting voltage: DC (12-24V), internally generated
Input current: 2.5mA – constant current regulated
Minimum input voltage: 0V (input shorted to common)
Maximum input voltage: DC 150V (diode protected against polarity reversal)
Filtering: De-bouncing with 50ms delay time
Detection scan rate: 100ms
Isolation: AC 2500V system to inputs
Operating Temperature: (-20 to +70) °C
Storage Temperature: (-40 to +80) °C
Relative air humidity: Maximum 95%, non-condensing
EMC - Immunity Interference: EN61000-4-2
Weight: 1.3oz
Dimensions (inch) W x H x L: 0.72 x 2.68 x 3.26
External Connection: AWG 12-26/(0.129 - 3.31)mm
2
13 pin, 3.5mm pluggable terminal block
The meter automatically recognizes the installed option card during Power Up. If you have not programmed a con-
guration for the card, the unit will default to the following outputs:
Status Inputs Defaulted to Status Detect
Pulse Outputs Defaulted to Energy Pulses
Pulse Channel 1 1.8 +Watt-hrs per pulse
Pulse Channel 2 1.8 -Watt-hrs per pulse
Pulse Channel 3 1.8 +VAR-hrs per pulse
Pulse Channel 4 1.8 -VAR-hrs per pulse
