6-2 IM02601001E www.eaton.com
Using the PXM 2000 Series
Using the Front Panel
You can access four modes using the meter’s front panel buttons:
• Operating Mode (Default)
• Reset Mode
•
• Information Mode. Information Mode displays a sequence of screens that show model information, such as
and.
Use the Menu, Enter, Down and Right buttons to navigate through each mode and its related screens.
•
Appendix A
contains the complete for the front panel display modes and their screens.
• The meter can also be congured from the web pages; see Chapter 8
for instructions.
Upon Power Up, the meter displays a sequence of screens:
• where all LEDs are lit
• where all digits are lit
• Firmware Screen showing build number
• Error Screen (if an error exists).
After startup, if auto-scrolling is enabled, the meter scrolls the parameter readings on the right side of the
front panel. The Kilo or Mega LED lights, showing the scale for the Wh, VARh and VAh readings. Figure 6.3
shows an example of a Wh reading.
The meter continues to provide scrolling readings until one of the buttons on the front panel is pressed,
causing the meter to enter one of the other Modes.
Figure 6.3: Wh Reading
