www.eaton.com IM02601001E 10-11
Setup on the Web Server Pages
Time=09/24/2009 00:00:48
Serial Number=0036216826
MAC=00:20:85:00:FF:EA
Location=Meter Location
Model=PXM2270
The email also includes two comma-separated les containing a trend log le with the
last 1000 entries and an event log le with the last 100 entries.
E-mail Setup Page
The meter provides authentication conguration for both SNMP version 1 and version 3,
and you can enable/disable either or both protocols. You can also specify up to six trap
recipients. You can review/download the various supported management information
bases (MIBs) by clicking Help and then clicking Protocol Documents.
Note that the requirements for the two protocols are different. For SNMP 1 you are only
required to provide a read-only and read-write community string. However, SNMP 3
requires separate usernames and passphrases (passwords) for both read and write privi-
leges. Consult your SNMP software documentation for more information.
