www.eaton.com IM02601001E 6-3
Using the PXM 2000 Series
Using the Main Menu
1. Press the Menu button. The Main Menu screen appears.
• The Reset: Demand mode (rStd) appears in the A window. Use the Down button to scroll, causing the
(rStE), ( (, and modes to move to the
.
• The mode that is currently ashing in the window is the “” mode, which means it is the mode that can
be congured.
For example: Press moves to A window. Press Down Twice - OPr moves to A window.
If the PXM 2000 Meter has an Ethernet Gateway card, there is an IP menu option after InFo mode. Press
Enter when IP is in the A window to see the IP Address. The IP address is displayed with 4 characters to a line, e.g.,
an IP address of 111.222.333.444 would appear as:
111.2
22.33
3.444
Note that it may take 2-3 minutes after Power up for the IP Address to display.
2. Press the Enter button from the Main Menu to view the Parameters screen for the mode that is currently
active.
Using Reset Mode
Reset Mode has two options:
(rStd): resets the Max and Min values.
(rStE): resets the energy accumulator elds.
Press the Enter button while either rStd or rStE is in the A window.
The screen appears.
• If you press the Enter button again, the Main Menu appears,
with the next mode in the A window. (The Down button
does not affect this screen.)
• If you press the Right button, the or
screen appears.
Press Enter to perform a reset.
If Password Protection is enabled for Reset, you must
enter the four digit Password before you can reset the meter.
(See Chapter 8 for information on Password Protection.)
page.
resets all Max and Min values.
Once you have performed a reset, the screen displays either “rSt dMd donE” or “rSt EnEr donE”and then resumes
auto-scrolling parameters.
