For more information visit: www.eatonelectrical.com RP01400001E
Renewal Parts
Page 34 Effective: February 2009
Current Cutler-Hammer
Panelboards
PRL5P Parts Section Page
PRL5P Chassis Layout . . . . . . . 35
PRL5P Breaker Adapter Unit
Catalog Numbers . . . . . . . . . . 36
PRL5P Branch Breaker
Information . . . . . . . . . . . . . . . 37
PRL5P Main or
Through-Feed Lugs . . . . . . . . 38
PRL5P Neutrals and Grounds . . 39
PRL5P Boxes, Trims and
Filler Plates . . . . . . . . . . . . . . . 40
Ordering Procedure
Step 1 Select the correct part
or Branch Device. When
selecting, you need to know
the following:
■ Panelboard type.
■ Amperage.
■ System voltage.
■ Available short circuit rating.
■ Number of poles available.
■ Size and number of wires
per phase.
■ “X” space required.
Step 2 Refer to the 5P panelboard
layout on Page 35 to verify the
amount of “X” space available.
Step 3 Create a 5P breaker unit
catalog number, by following
the instructions on Page 36, or
order the catalog number for
parts on Pages 38 through 40.
Step 4 Determine if extra filler covers
are required. Additional filler
covers may be necessary to
fill the unused space. Refer
to Page 40 for filler plate
information.
