103
© 2017 Eaton. All rights reserved
2018.12.12
MHP/MXP/VHP/VXP Splitter Gear Bearing Disassembly and Assembly | Service Procedures TRSM0940
Splitter Gear Bearing Disassembly
1. Remove the internal coiled snap ring.
2. Remove
the Tapered Bearing Pack Assembly using
bearing driver RR1012TR-4.
3. Separate the Bearing
Pack Assembly.
