Eaton UltraShift PLUS Series - Output Shaft Speed Sensor Removal

217
© 2017 Eaton. All rights reserved
2018.12.12
Output Shaft Speed Sensor Removal and Installation | Service Procedures TRSM0940
Output Shaft Speed Sensor Removal
1. Disconnect the Transmission Harness from the Output
Shaft Speed Sensor pigtail connector.
2. Remove the
sensor retaining bolt.
3. Remove the speed sensor
from the Transmission Rear
Bearing Cover.
