LAS/VAS Auxiliary Section Removal and Disassembly | Service Procedures TRSM0940
Range Synchronizer Assembly
1. Install the Sliding Clutch on the Blocker Pins with the
recessed side up.
2. Install
the three springs into the bores of the High
Range Synchronizer Ring.
3. Place
the High Range Synchronizer Ring over the
Blocker Pins of the Low Range Synchronizer, seating
the springs against the pins.
