2018.12.12
© 2017 Eaton. All rights reserved
14
TRSM0940 Service Procedures | LAS/VAS Auxiliary Section Removal and Disassembly – In Chassis
In Chassis
1. Drain the oil.
2. Disc
onnect the OEM supplied air line. (Refer to Air Line
disconnection for the procedure.)
3. Disc
onnect the driveline a move out of the way.
4. Disc
onnect the Wiring Harness from the Range Sole-
noid Valve and speed sensor.
5. If any OEM equipment needs to be removed refer to the
OEM fo
r guidelines.
6. Remove the
19 bolts securing the Auxiliary Section to
the Transmission.
7. Put the removal jack
in place and secure to the Auxil-
iary Section.
8. Slo
wly remove the Auxiliary Section from the Main
Case and the dowel pins.
9. Once
the Auxiliary Section is on the bench, go to
LAS/VAS Auxiliary Section
Removal and Disassembly
on page 15.
