TRSM0940 Service Procedures | MHP/MXP/VHP/VXP Auxiliary Section Removal and Disassembly
9. Using an overhead crane or hoist, remove the Auxiliary
Section with the auxiliary section hanger.
Auxiliary Section Disassembly
1. Too ease in the disassembly of the Auxiliary Section.
Place in a vise.
2. Remove the 15/16” nut that fastens the Range Cylinder
Asse
mbly to the range shift Yoke bar.
