Oil Pump and Lube Tube Installation | Service Procedures TRSM0940
3. Install the two cap screws securing the Main Feed Tube
to the Transmission Main Case.
Main Case Gear Timing and Assembly
1. Using the “O” stamped onto the rear of the Main Case
Counter Shafts, mark the corresponding tooth on the
Main Drive Gear set (front gear) with highly visible ink
or dye.
