MHP/MXP/VHP/VXP Auxiliary Section Assembly and Installation | Service Procedures TRSM0940
4. Install the Splitter Gear on the Output Shaft
Note: For
Splitter Gear Disassembly and Assembly, see
the section: Splitter Gear Bearing Disassembly &
Assembly, in this manual.
5. Install
the Splitter Gear retainer and 15/16” cap screw.
Torque to 190-210 lb-ft (257.61-284.72 N•m).
Note: E
nsure proper torque is applied to the retainer
bolt.
