Input Shaft Removal and Installation | Service Procedures TRSM0940
Replacing Input Shaft without Disassembling
the Main Case or Removing Clutch Housing
1. Remove the six cap screws fastening the Front Bearing
Cover to the Transmission Main Case.
2. If present, remove
and discard the rubber seal on the
Input Shaft. This rubber seal is only used to seal the
Transmission during shipment.
3. Remove
the snap ring from the Input Shaft.
4. Using a s
oft maul drive the Input Shaft towards the
rear of the Transmission Case as far as possible. Pull
the Input Shaft forward.
5. Install
the Input Shaft Bearing Remover and remove
the bearing from the Transmission Main Case.
Note: A
pry bar or screwdriver may also be used to
remove the Input Shaft Bearing.
