TRSM0940 Appendix | Torque Specifications
12. Air Filter Regulator Cap Screws 2 0.25" 20 8–12 lb-ft (11–16 N•m)
13. Rear Bearing cover Cap Screws 6 0.375" 16 30–35 lb-ft (41–47 N•m)
14. Thermocouple Plug 1 0.50" 40–50 lb-ft (54–67 N•m)
15. Hand Hole Cover Cap Screws 4 0.321" 18 14–18 lb-ft (19–24 N•m)
16. Provision for PTO Bracket 2 0.375" 16 30–35 lb-ft (41–47 N•m)
17. 8-Bolt PTO Cover Cap Screws 8 0.4375" 14 50–65 lb-ft (68–88 N•m)
18. Oil Fill Plug 1 1.0625" 12 35–50 lb-ft (47–67 N•m)
19. Oil Level Sight Glass Plug 1 0.625" 12 60–70 lb-ft (82–95 N•m)
20. Output Yoke Retainer Bolts 2 M12 1.25 84–92 lb-ft (113–124 N•m)
21. Auxiliary Housing Cap Screws 19 0.375" 16 35–45 lb-ft (48–61 N•m)
22. Auxiliary Counter Shaft Rear Bearing Cover Cap
Scr
ews
8 0.375" 16 30–35 lb-ft (41–47 N•m)
23. Speed Sensor Retaining Bolt 1 0.25" 20 8–12 lb-ft (11–16 N•m)
Description Qty. Size TPI Torque
