LAS/VAS Auxiliary Section Assembly and Installation | Service Procedures TRSM0940
5. Mark any two teeth 180 degrees apart on the Range
Reduction Gear using a highly visible dye.
6. Place the
inner bearing (longer rollers) tapered side up
over the Auxiliary Main Shaft.
7. Drive the bearing d
own to the Auxiliary Reduction Gear
using the Output Shaft Bearing Driver.
8. Slide the bearing sp
acer down on top of the inner bear-
ing.
