Eaton UltraShift PLUS Series User Manual

45
© 2017 Eaton. All rights reserved
2018.12.12
VCS/VMS Auxiliary Section Removal and Disassembly | Service Procedures TRSM0940
Component Identification
1. Spring
2. Synchronizer Assembly
3. Sliding Clutch
4. Synchronizer Assembly
5. Nut
6. Dowel Pin
7. Washer
8. Washer
9. Reduction Gear
10. Bushing
11. Mainshaft Assembly
12. Pin
13. Sliding Clutch
14. Mainshaft
15. Washer
16. Deep Reduction Gear
17. Washer
18. Output Yoke Retainer Flange
19. Hex Flange Head Screw
20. Tapered Roller Bearing
21. Universal Joint Yoke
1
2
3
18
4
5
6
7
8
9
10
11
12
13
14
15
10
12
19
16
17
20
21
