EchoNous Bladder & Vein User Guide 69
System connectivity
USING THE ECHONOUS AI STATION MOBILE STAND
LOCKING THE WHEELS
All four caster wheels are capable of locking. Press the lock button with your foot. The caster is locked when the
lock button is out. The caster is unlocked when the lock button is in.
A
DJUSTING THE HEIGHT OF COMPONENTS
All components are capable of being adjusted up or down the central column of the AI Station.
1. Press the thumb button on the collar.
2. Support the weight of the component with one hand.
3. While depressing the thumb button, pull the collar handle open. The handle may be tightly engaged and
requires a screw driver to gently pry open.
4. With the collar handle open, use both hands to move the component to the desired position.
5. Push the collar handle closed. The thumb button on the collar should automatically fall into place.
TABLE 1. Safe working loads and installation heights of all components
Component
Mounting Height Range (measured
from top of central column) Safe Working Load
Tablet holder 0” - 11” (bottom of range limited by
safety stop)
0 cm - 28 cm
As configured (no storage)
Handle bar assembly 13” - 23” (top of range limited by
safety stop)
33 cm - 58 cm
3 lbs on each side (6 lbs total)
1.3 kg on each side (2.6 kg total)
Lower bin assembly 30” - 36”
76 cm - 91 cm
4 lbs on each side (8 lbs total)
1.8 kg on each side (3.6 kg total)
Cord wrap Below lower bin As configred (no storage)
The cord wrap must be installed as the lowest component on the AI
Station Mobile Stand to protect the handle bar assembly against falling
down into the caster base.
• When opening the collar handles for components on the AI Station, it
is important to support the component’s weight to avoid damage or
injury from falling components.
• When adjusting the height of the display unit on the EchoNous AI
Station, it is important to safely manage the DC power cord to avoid
damage to the cord and risk of electric shock.
