Technical Publication Document NO: SYSTEM-007-ENG (Ver.1.1)
HF-525Plus Installation, Operation and Service Manual
(5) After selection of main category ‘Spine’ and select sub category with 4 parts as below.
(5) After selection of main category ‘Abdomen’ and select sub category with 4 parts as below.
When the main body part (Chest) is selected, press F3 to
find ‘Sternum view’ and the icon appears on LCD screen.
Select ‘Chest’ in top menu, and press F3 to fix it at ‘AUX2’
then the selected body part appears on LCD screen.
AUX2 is the category that users can program additional
desired parameters for APR.
With Spine selected, press F3 to select at ‘C-Spine’ then its
body part appears on LCD screen.
With Spine selected, press F3 to select ‘L-Spine’ then the
body part will appear on LCD screen.
With Spine selected, press F3 to select ‘T-Spine’ then the
body part will appear on LCD screen..
With Spine selected, press F3 to select ‘AUX3’ then the
body part will appear on LCD screen. AUX3 is an
additional program bank where users can put extra desired
parameters for APR.
With Abdomen selected, press F3 to select at ‘Abdomen’
then its body part appears on LCD screen.
