5.9.5.8 AEC Chamber & Control board’s Control Method
NOTE ▶
AEC is Option, and AEC Chamber’s User / Installation Manual is provided Separately.
3
Field Ⅰ
and, AEC Chamber’s
Auxiliary Signal and
P801, Table Signal,
P803, Upright stand
Signal, and P802 Signal
all Connected.
4
Reset
Reset / exposure
5
AEC2 stop
Output signal ramp
6
Field Ⅲ
7
AEC2 -VDC
-12V
8
AEC2 +VDC
+12V
9
GND
Shield
