Ecotech Serinus 44 User Manual

Service
Page 113
6. Service
6.1 Maintenance Tools
To perform general maintenance on the Serinus 44 you may require the following equipment:
 Customizable Test Equipment Case PN: H070301
 Digital Multimeter & Leads (DMM) PN: E031081 & E031082
 Barometer PN: E031080
 Thermometer & Probe PN: E031078 & E031079
 Flow Meter (Select Range)
Range: 50 sccm to 5000 sccm PN: ZBI-200-220M
Range: 300 sccm to 30000 sccm PN: ZBI-200-220H
 Minifit Extraction Tool PN: T030001
 Orifice/Sintered Filter Extraction Tool PN: H010046
 Leak Test Jig PN: H050069
 Computer/Laptop and Connection Cable for Diagnostic Tests
 1.5mm hex key
 Assortment of 1/4” and 1/8” Tubing and Fittings
 Zero Air Source
 Span Gas Source
Figure 50 – Minifit Extraction Tool – (T030001)
Figure 51 – Orifice/Sintered Filter Removal Tool – (H010046)
