Acclarix AX8/Acclarix AX7 Diagnostic Ultrasound System User Manual Measurements and Reports
- 114 -
No.
Measurement
Group
Measurement
Item
Description
Method
Hep D Vel
Hepitic Vein diastole velocity
Hep. A Vel
Hepitic Vein A-wave reverse
velocity
Hep A Dur
Hepitic Vein A-wave Duration
2.16
PISA
MR Trace
Mitral Valve Trace
PISA (See
section 8.2.4.2)
AR Trace
Aortic Valve Trace
TR Trace
Tricuspid Valve Trace
PR Trace
Pulmonary Valve Trace
2.17
TDI
Sa Medial
Mitral Valve Medial Systolic Motion
Doppler generic
measurements
Ea Medial
Mitral Valve Medial Early Diastolic
Motion
Aa Medial
Mitral Valve Medial Late Diastolic
Motion
Sa Lateral
Mitral Valve Lateral Systolic Motion
Ea Lateral
Mitral Valve Lateral Early Diastolic
Motion
Aa Lateral
Mitral Valve Lateral Late Diastolic
Motion
2.18
HR
Heart rate
HR in Doppler
generic
measurements
Section 3: M-mode Measurements
3.1
LV/RV
RVAWd
Right Ventricular Anterior Wall
Thickness at End-diastole
M-mode generic
measurements
RVIDd
Right Ventricular Internal Diameter
at end-diastole
IVSTd
Interventricular Septal Thickness at
End-diastole
LVIDd
Left Ventricular Internal Diameter at
End-diastole
LVPWd
Left Ventricular Posterior Wall
Thickness at End-diastole
IVSTs
Interventricular Septal Thickness at
End-systole
LVIDs
Left Ventricular Internal Diameter at
End-systole
